1524788 | Phoenix Contact
Socket, M8, 3 pole, solder pins, screw locking, straight, 1524788
Order No.: 61P8844
EAN: 4017918953881
MPN:
1524788
SACC-DSIV-M 8FS-3CON-L 90
Unit Price (€ / pc.)
10.115 € *
Available: 0 pcs.
Leadtime: On Request **
Sensor-actuator connector, 1524788, Phoenix Contact
Sensor/actuator flush-type connector, socket, 3-pole, M8, rear/screw mounting with M8 thread, with polarity protection, with angled solder connection.
Features
- Unshielded
- A-coded
- Overvoltage category: II
- Pollution degree: 3
- Degree of protection: IP67
Applications
- For transmission of signals
Technical specifications
| Version | socket | |
| Thread size | M8 | |
| Coding | A | |
| Contact connection | solder pins | |
| contact surface | gold-plated | |
| Assembly | rear/screw mounting | |
| Orientation | straight | |
| Pin number | 3 pole | |
| Degree of protection (IP) | IP67 | |
| Type of locking | screw locking |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
