1413933 | Phoenix Contact

Plug, M12, 2 pole, IDC connection, screw locking, straight, 1413933

Order No.: 61P9397
EAN: 4055626013152
MPN:
1413933
SACC-MS-4QO SH PBPA SCO
Series: SACC
1413933 Phoenix Contact Sensor-Actuator Connectors
Image may differ
Unit Price (€ / pc.)
43.6849 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
43.68 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
43.6849 €

Sensor-actuator connector, 1413933, Phoenix Contact

Data connector, PROFIBUS PA (31.25 kbps), 2-position, halogen-free, shielded, plug straight M12 SPEEDCON, Insulation displacement connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 5 mm - 9.7 mm.

Features

  • Safe use in the field, thanks to a high degree of protection
  • Fast locking system
  • Reliable signal transmission
  • A-coded
  • Pollution degree: 3
  • Overvoltage category: II
  • Degree of protection: IP67
Technical specifications
Pin number 2 pole
Type of locking screw locking
Contact connection IDC connection
Product type plug
Coding A
Assembly cable assembly
Orientation straight
Degree of protection (IP) IP65/IP67
Thread size M12
contact surface nickel-plated/gold-plated
Logistics
Customs tariff number 85366990
Country of origin DE
Compliance
SVHC free Yes
RoHS conform Yes
Date of RoHS guidelines 3/31/15
