1071465 | Phoenix Contact

Panel socket, M8, 4 pole, screw locking, straight, 1071465

Order No.: 61P8436
EAN: 4055626758817
MPN:
1071465
SACC-CI-M8FS-4P SMD SH R32 WO
Series: SACC
1071465 Phoenix Contact Sensor-Actuator Connectors Image 1
1071465 Phoenix Contact Sensor-Actuator Connectors Image 2
Image may differ
Unit Price (€ / pc.)
4.6529 € *
Available in 10 days: 200 pcs. - if ordered today
Total Price:
465.29 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 pcs.
4.6529 €

Sensor-actuator connector, 1071465, Phoenix Contact

Flush-type connector, 4-position, Socket, straight, M8, PCB mounting.

Features

  • Easy device integration
  • Two-piece device connector
  • A-coded
  • Contact material: CuZn
  • Overvoltage category: III
  • Flammability rating according to UL 94: V0
Technical specifications
Filter Property Value
Pin number 4 pole
Assembly PCB mounting
Product type panel socket
Coding A
Orientation straight
Degree of protection (IP) IP67
Thread size M8
contact surface gold-plated
Type of locking screw locking
Logistics
Property Value
Customs tariff number 85366990
Country of origin DE
Compliance
Property Value
RoHS conform Yes
Substance description Lead
SVHC free No
Date of RoHS guidelines 3/31/15
