1411115 | Phoenix Contact
Locking screw, external hexagon, M63, Ø 77 mm, 24 mm, brass
Order No.: 60P6284
EAN: 4046356922302
MPN:
1411115
A-EXSH-M63-68L-N-S
Unit Price (€ / pc.)
68.6749 € *
Available: 0 pcs.
Leadtime: 9 Weeks **
Screw plug A-EXSH-M63-68L-N-S
Screw plug, Material screw connection: Brass nickel plated, Application: Ex, Connection thread: M63 x 1.5, Color: silver
The technical features of 1411115 from Phoenix Contact at a glance
- Tolerance specification (based on standard): not applicable
- Impact resistant available: No
- Screw length: 24 mm
- Width across flats: 65 mm
- Material (according to standard): not available
- Material: Brass nickel plated
- Drive size: not applicable
- Output of the dimensional standard: not available
- Item Designation: A-EXSH-M63-68L-N-S
- Color: silver
- Order suffix coded: not applicable
- Order suffix (based on standard): not applicable
- Product class (based on standard): not applicable
- Product class: not applicable
- Surface protection (based on standard): not available
- Surface protection: Nickel
- Nominal thread size NPT/gas pipe thread (imperial): Not relevant
- Thread size: M63
- Thread type: metric
- Thread direction: right
- Thread pitch: 1.5 mm
- Thread design as code letter (based on standard): not applicable
- Thread pitch at nut end: 1.5 mm
- Nominal thread size PG (metric : M63
- Head diameter of the screw: 77 mm
- glass fiber reinforced: No
- halogen free: No
- Withworth pipe thread (d1): not applicable
Technical specifications
Version | locking screw | |
diameter | 77 mm | |
Spindle drive type | external hexagon | |
Thread size | M63 | |
Length | 24 mm | |
Material | brass |
Download
Logistics
Country of origin | GB |
Customs tariff number | 74198090 |
Compliance
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | No |
Substance description | Lead |
