1705668 | Phoenix Contact
PCB terminal, 3 pole, pitch 7.5 mm, AWG 24-10, 41 A, screw connection, green, 1705668
Unit Price (€ / pc.)
6.5569 € *
Standard delivery time from the manufacturer is: On Request
PCB terminal, 1705668, Phoenix Contact
PCB terminal block, nominal current: 41 A, rated voltage (III/2): 320 V, nominal cross section: 4 mm², number of potentials: 3, number of rows: 1, number of positions per row: 3, pitch: 7.5 mm, connection method: screw connection with tension sleeve, screw head form: L slotted, conductor/PCB connection direction: 0 °, color: green, pin layout: linear pinning, solder pin: 5 mm, number of solder pins per potential: 2.
Features
- Low temperature rise, thanks to maximum contact force
- Allows connection of two conductors
- Quick and convenient testing using integrated test option
- Potentials can be easily looped through with additional connection to the PCB
- Two solder pins reduce the mechanical strain on the soldering spots
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 24-10 | |
| Rated current | 41 A | |
| Height | 23 mm | |
| Colour | green | |
| Assembly | THT | |
| Width | 22.5 mm | |
| Grid | 7.5 mm | |
| Rated voltage | 320 V | |
| Connection | screw connection | |
| Pin number | 3 pole | |
| Cable cross-section | 0.2-6.0 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
