1704059 | Phoenix Contact
PCB terminal, 1 pole, pitch 10 mm, AWG 20-6, 76 A, screw connection, green, 1704059
Unit Price (€ / pc.)
3.8199 € *
Available: 30 pcs.
Available in 10 days: 3,500 pcs. - if ordered today
PCB terminal, 1704059, Phoenix Contact
PCB terminal block, nominal current: 76 A, rated voltage (III/2): 320 V, nominal cross section: 10 mm², number of potentials: 1, number of rows: 1, number of positions per row: 1, pitch: 10 mm, connection method: screw connection with tension sleeve, conductor/PCB connection direction: 0 °, color: green, pin layout: linear pinning, solder pin: 4.3 mm, number of solder pins per potential: 4.
Features
- Low temperature rise, thanks to maximum contact force
- Allows connection of two conductors
- Potentials can be easily looped through with additional connection to the PCB
- The latching on the side enables various numbers of positions to be combined
Technical specifications
| Rated voltage | 320 V | |
| Rated current | 76 A | |
| Connection | screw connection | |
| Cable cross-section | 0.5-16 mm² | |
| Height | 33.3 mm | |
| Grid | 10 mm | |
| Colour | green | |
| Width | 10 mm | |
| Pin number | 1 pole | |
| AWG cross-section | AWG 20-6 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
