1701023 | Phoenix Contact
PCB terminal, 1 pole, pitch 5 mm, AWG 26-14, 17.5 A, screw connection, green, 1701023
Unit Price (€ / pc.)
1.8326 € *
Available in 10 days: 3,823 pcs. - if ordered today
Total Price:
1.83 € *
Price list
Quantity
Price per unit*
1 pcs.
1.8326 €
10 pcs.
1.6779 €
50 pcs.
1.5351 €
100 pcs.
1.3685 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal, 1701023, Phoenix Contact
PCB terminal block, nominal current: 17.5 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², number of potentials: 1, number of rows: 1, number of positions per row: 1, pitch: 5 mm, connection method: screw connection with tension sleeve, conductor/PCB connection direction: 0 °, color: green, pin layout: linear pinning, solder pin: 4.9 mm, number of solder pins per potential: 2.
Features
- Low temperature rise, thanks to maximum contact force
- Allows connection of two conductors
- Quick and convenient testing using integrated test option
- Two solder pins reduce the mechanical strain on the soldering spots
- The latching on the side enables various numbers of positions to be combined
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height | 19 mm | |
| Rated voltage | 400 V | |
| AWG cross-section | AWG 26-14 | |
| Width | 5 mm | |
| Cable cross-section | 0.14-2.5 mm² | |
| Pin number | 1 pole | |
| Connection | screw connection | |
| Colour | green | |
| Grid | 5 mm | |
| Assembly | THT | |
| Rated current | 17.5 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PL |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
