1118059 | Phoenix Contact
PCB terminal, 6 pole, pitch 5.08 mm, AWG 24-14, 12 A, spring-clamp connection, green, 1118059
Unit Price (€ / pc.)
8.4133 € *
Available in 5 Days: 200 pcs. - if ordered today
Total Price:
8.41 € *
Price list
Quantity
Price per unit*
1 pcs.
8.4133 €
10 pcs.
7.8421 €
50 pcs.
7.3542 €
100 pcs.
6.9139 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal blocks, 1118059, Phoenix Contact
Printed circuit board terminal, nominal current: 12 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², number of rows: 3, number of positions per row: 6, product range: ZFK3DS(A) 1,5, pitch: 5.08 mm, connection method: Spring-cage connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.4 mm, number of solder pins per potential: 1.
Features
- Defined contact force ensures that contact remains stable over the long term
- Clamping space opened by means of fixed screwdriver enables convenient conductor connection
- Conductor connection on several levels enables higher contact density
- The latching on the side enables various numbers of positions to be combined
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | spring-clamp connection | |
| Width | 31.48 mm | |
| Colour | green | |
| Pin number | 6 pole | |
| AWG cross-section | AWG 24-14 | |
| Rated voltage | 400 V | |
| Assembly | THT | |
| Height | 40 mm | |
| Rated current | 12 A | |
| Cable cross-section | 0.2-2.5 mm² | |
| Grid | 5.08 mm | |
| Depth | 32.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
