1071068 | Phoenix Contact

PCB terminal, 4 pole, pitch 5 mm, AWG 24-16, 16 A, push-in spring connection, green, 1071068

Order No.: 64P2448
EAN: 4063151101015
MPN:
1071068
SPTAF 1/ 4-5,0-IL-EX
Series: SPTAF
1071068 Phoenix Contact PCB Terminal Blocks
Image may differ
Unit Price (€ / pc.)
2.38 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
2.38 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
2.38 €

PCB terminal block, 1071068, Phoenix Contact

PCB terminal block, Nominal current: 16 A, Nominal cross section: 1.5 mm², Number of rows: 1, Number of positions per row: 4, Product range: SPTAF 1/.-IL-EX, Pitch: 5 mm, Connection method: Push-in spring connection, Mounting: Wave soldering, Conductor/PCB connection direction: 45 °, Color: green, Pin layout: Linear pinning, Solder pin [P]: 2.6 mm, Number of solder pins per potential: 2. Suitable for CAT5

Technical specifications
Colour green
Depth 11 mm
AWG cross-section AWG 24-16
Rated current 16 A
Grid 5 mm
Width 20 mm
Height 10.6 mm
Cable cross-section 0.2-1.5 mm²
Pin number 4 pole
Connection push-in spring connection
Rated voltage 137 V
Logistics
Country of origin PL
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free No
RoHS conform Yes
