1967375 | Phoenix Contact
Socket header, 2 pole, pitch 10.16 mm, straight, green, 1967375
Unit Price (€ / pc.)
6.0095 € *
Available: 90 pcs.
Available in 5 Days: 2,703 pcs. - if ordered today
Total Price:
6.01 € *
Price list
Quantity
Price per unit*
1 pcs.
6.0095 €
10 pcs.
5.2717 €
100 pcs.
4.6410 €
250 pcs.
4.4744 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Connector, 1967375, PHOENIX
PCB plug, rated current: 76 A, rated voltage (III/2): 1000 V, number of poles: 2, grid spacing: 10.16 mm, connection type: screw connection with tension sleeve, color: green, contact surface: silver.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | green | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Connection | screw connection | |
| Rated voltage | 1 kV | |
| Orientation | straight | |
| Type of locking | No | |
| contact surface | tin-plated | |
| Version | socket header | |
| Pin number | 2 pole | |
| Contact type | socket | |
| Grid | 10.16 mm | |
| Rated current | 76 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
