1963764 | Phoenix Contact

Pin header, 3 pole, pitch 2.5 mm, straight, black, 1963764

Order No.: 63P3098
EAN: 4017918917357
MPN:
1963764
MCV 0,5/ 3-G-2,5 THT R44
Series: MCV
1963764 Phoenix Contact PCB Connection Systems Image 1
1963764 Phoenix Contact PCB Connection Systems Image 2
1963764 Phoenix Contact PCB Connection Systems Image 3
1963764 Phoenix Contact PCB Connection Systems Image 4
Image may differ
Unit Price (€ / pc.)
1.4994 € *
Available: 0 pcs.
Available in 10 days: 440 pcs.
Leadtime: 2 Weeks **
Total Price:
1.50 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
1.4994 €
Technical specifications
Number of rows 1
Rated voltage 160 V
Contact type pin
Type of locking No
Connection solder connection
contact surface tin-plated
Pin number 3 pole
Grid 2.5 mm
Orientation straight
Additional parts equipped
Colour black
Version pin header
Rated current 4 A
Logistics
Country of origin DE
Customs tariff number 85366930
Compliance
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
