1910830 | Phoenix Contact
Pin header, 3 pole, pitch 5 mm, straight, green, 1910830
Unit Price (€ / pc.)
3.0821 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
3.08 € *
Price list
Quantity
Price per unit*
1 pcs.
3.0821 €
10 pcs.
2.8322 €
50 pcs.
2.5704 €
100 pcs.
2.3324 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection plating | tin-plated | |
| Connection | push-in spring connection | |
| Number of rows | 1 | |
| Colour | green | |
| contact surface | tin-plated | |
| Type of locking | Yes | |
| Version | pin header | |
| Orientation | straight | |
| Additional parts | equipped | |
| Rated current | 12 A | |
| Pin number | 3 pole | |
| Grid | 5 mm | |
| Rated voltage | 320 V | |
| Contact type | pin |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
