1862603 | Phoenix Contact
Socket, 5 pole, pitch 3.81 mm, angled, green, 1862603
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
3.7842 € *
Available in 5 Days: 950 pcs. - if ordered today
Total Price:
3.78 € *
Price list
Quantity
Price per unit*
1 pcs.
3.7842 €
10 pcs.
3.4867 €
50 pcs.
3.1654 €
100 pcs.
2.8560 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB header, 1862603, Phoenix Contact
PCB headers, Nominal cross section: 1.5 mm2, Color: green, Nominal current: 8 A, Rated voltage (III/2): 160 V, Contact surface: tin, Type of contact: female connector, Number of potentials: 5, Number of rows: 1, Number of positions: 5, Number of connections: 5, Product range: IMC 1.5-G, Pitch: 3.81 mm, Mounting: wave soldering, Pin layout: linear pinning, Solder pin [P]: 3.4 mm, Number of solder pins per potential: 2, Plug-in system: COMBICON MC 1,5, Pin connector pattern alignment: Standard, Locking: without, Mounting: without.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | PCB connector | |
| Contact type | socket | |
| Pin number | 5 pole | |
| Grid | 3.81 mm | |
| Connection | PCB connection | |
| Orientation | angled | |
| Type of locking | No | |
| contact surface | tin-plated | |
| Connection plating | tin-plated | |
| Rated voltage | 160 V | |
| Rated current | 8 A | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Breakable | No | |
| Colour | green |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
