1837462 | Phoenix Contact
Pin header, 12 pole, pitch 5 mm, straight, black, 1837462
Unit Price (€ / pc.)
4.0222 € *
Standard delivery time from the manufacturer is: 5 Weeks
Printed-circuit board connector, 1837462, Phoenix Contact
PCB header, nominal cross section: 2.5 mm², color: black, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 12, Number of rows: 1, Number of positions per row: 12, number of connections: 12, product range: CCV 2,5/..-GF-LR, pitch: 5 mm, mounting: THR soldering, pin layout: Linear pinning, solder pin [P]: 2 mm, plug-in system: CLASSIC COMBICON, Locking: Snap-in locking, type of packaging: packed in cardboard
Features
- Designed for integration into the SMT soldering process
- Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
- Screwable flange for superior mechanical stability
- Automatic locking and intuitive release through Lock and Release operating lever in contrasting color
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5 mm | |
| contact surface | tin-plated | |
| Connection | solder connection | |
| Orientation | straight | |
| Contact type | pin | |
| Version | pin header | |
| Rated current | 12 A | |
| Colour | black | |
| Rated voltage | 320 V | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Type of locking | Yes | |
| Connection plating | tin-plated | |
| Pin number | 12 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
