1833140 | Phoenix Contact
Pin header, 14 pole, pitch 3.81 mm, straight, green, 1833140
Unit Price (€ / pc.)
16.2792 € *
Available in 5 Days: 291 pcs. - if ordered today
PCB Connector, 1833140, PHOENIX
PCB plug, rated current: 8 A, rated voltage (III/2): 320 V, number of poles: 4, grid dimension: 5.08 mm, connection type: screw connection with tension sleeve, color: green, contact surface: tin.
Technical specifications
Filter | Property | Value |
---|---|---|
Connection plating | tin-plated | |
Connection | screw connection | |
Colour | green | |
Additional parts | equipped | |
Pin number | 14 pole | |
Contact type | pin | |
Orientation | straight | |
Type of locking | Yes | |
Rated voltage | 160 V | |
contact surface | tin-plated | |
Version | pin header | |
Rated current | 8 A | |
Number of rows | 1 | |
Grid | 3.81 mm |
Download
Logistics
Property | Value |
---|---|
Country of origin | PL |
Customs tariff number | 85366990 |
Compliance
Property | Value |
---|---|
RoHS conform | Yes |
SVHC free | Yes |
Date of RoHS guidelines | 3/31/15 |
