1830606 | Phoenix Contact
Pin header, 3 pole, pitch 3.81 mm, straight, green, 1830606
Unit Price (€ / pc.)
2.5466 € *
Available: 147 pcs.
Available in 10 days: 10,999 pcs. - if ordered today
Total Price:
2.55 € *
Price list
Quantity
Price per unit*
1 pcs.
2.5466 €
25 pcs.
2.1777 €
100 pcs.
2.0111 €
250 pcs.
1.9159 €
1000 pcs.
1.7255 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Connector, 1830606, PHOENIX
Printed circuit board base strip, rated current: 8 A, rated voltage (III/2): 160 V, number of poles: 3, grid spacing: 3.81 mm, color: green, contact surface: tin, mounting: wave soldering.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 8 A | |
| Rated voltage | 160 V | |
| Version | pin header | |
| Number of rows | 1 | |
| Orientation | straight | |
| Additional parts | equipped | |
| contact surface | tin-plated | |
| Pin number | 3 pole | |
| Grid | 3.81 mm | |
| Type of locking | Yes | |
| Contact type | pin | |
| Colour | green | |
| Connection plating | tin-plated | |
| Connection | solder connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
