1829361 | Phoenix Contact
Pin header, 4 pole, pitch 3.81 mm, straight, green, 1829361
Unit Price (€ / pc.)
5.0099 € *
Available: 30 pcs.
Available in 5 Days: 5,450 pcs. - if ordered today
Total Price:
5.01 € *
Price list
Quantity
Price per unit*
1 pcs.
5.0099 €
10 pcs.
4.5220 €
50 pcs.
3.9627 €
100 pcs.
3.3796 €
*incl. VAT plus shipping costs
Subject to prior sale
Feed-through header, 1829361, Phoenix Contact
Feed-through header, Nominal cross section: 1.5 mm², Color: green, Nominal current: 8 A, Rated voltage (III/2): 160 V, Contact surface: Tin, Type of contact: Male connector, Number of potentials: 4, Number of rows: 1, Number of positions: 4, Number of connections: 4, Product range: DFK-MC 1,5/..-GF, Pitch: 3.81 mm, Connection method: Solder/Slip-on connection, Mounting: Direct mounting, pin layout: Linear pinning, Solder pin [P]: 9.4 mm, Number of solder pins per potential: 1, Plug-in system: COMBICON MC 1,5, Pin connector pattern alignment: Standard, Locking: Screw locking, Mounting: Threaded flange, Type of packaging: packed in cardboard.
Features
- Free choice – permanent solder connection or standardized slip-on connection
- Cable connection on the inside of the device enables flexible positioning of the panel feed-through
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 3.81 mm | |
| Pin number | 4 pole | |
| Colour | green | |
| Connection plating | tin-plated | |
| Contact type | pin | |
| Rated current | 8 A | |
| Version | pin header | |
| Connection | solder/plug-in connection | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Rated voltage | 160 V | |
| contact surface | tin-plated | |
| Orientation | straight | |
| Type of locking | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
