1828469 | Phoenix Contact

Socket header, 14 pole, pitch 3.81 mm, straight, green, 1828469

Order No.: 63P3712
EAN: 4017918114770
MPN:
1828469
MCVR 1,5/14-STF-3,81
Series: MCVR
1828469 Phoenix Contact PCB Connection Systems Image 1
1828469 Phoenix Contact PCB Connection Systems Image 2
Image may differ
Unit Price (€ / pc.)
10.0674 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
10.07 € *
Price list
Quantity
Price per unit*
1 pcs.
10.0674 €
10 pcs.
8.8536 €
50 pcs.
8.1396 €
100 pcs.
7.4018 €
*incl. VAT plus shipping costs
Subject to prior sale

PCB Connector, 1828469, PHOENIX

PCB plug, rated current: 8 A, rated voltage (III/2): 160 V, number of poles: 14, grid spacing: 3.81 mm, connection type: screw connection with tension sleeve, color: green, contact surface: tin.

Technical specifications
Filter Property Value
Grid 3.81 mm
Pin number 14 pole
Colour green
Connection plating tin-plated
Contact type socket
Rated current 8 A
Version socket header
Connection screw connection
Additional parts equipped
Number of rows 1
Rated voltage 160 V
contact surface tin-plated
Orientation straight
Type of locking Yes
Logistics
Property Value
Customs tariff number 85366990
Country of origin DE
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
