1821290 | Phoenix Contact
Pin header, 7 pole, pitch 2.54 mm, angled, black, 1821290
Order No.: 63P1824
EAN: 4046356789455
MPN:
1821290
MC 0,5/ 7-G-2,54 P20 THR R44
Series: COMBICON MC 0,5
Unit Price (€ / pc.)
1.9040 € *
Standard delivery time from the manufacturer is: On Request
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Type of locking | No | |
| contact surface | gold-plated | |
| Rated current | 6 A | |
| Grid | 2.54 mm | |
| Pin number | 7 pole | |
| Version | pin header | |
| Additional parts | equipped | |
| Orientation | angled | |
| Connection | solder connection | |
| Contact type | pin | |
| Rated voltage | 160 V | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PL |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
