1818546 | Phoenix Contact
Pin header, 6 pole, pitch 3.5 mm, angled, black, 1818546
Unit Price (€ / pc.)
3.3558 € *
Standard delivery time from the manufacturer is: 5 Weeks
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of rows | 2 | |
| Rated current | 8 A | |
| Contact type | pin | |
| Connection plating | tin-plated | |
| Grid | 3.5 mm | |
| Pin number | 6 pole | |
| Orientation | angled | |
| Rated voltage | 160 V | |
| Additional parts | equipped | |
| Type of locking | Yes | |
| Connection | solder connection | |
| contact surface | tin-plated | |
| Colour | black | |
| Version | pin header |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
