1788635 | Phoenix Contact
Pin header, 12 pole, pitch 5.08 mm, green, 1788635
Unit Price (€ / pc.)
10.3411 € *
Available in 5 Days: 1,500 pcs. - if ordered today
PCB Connector, 1788635, PHOENIX
Direct plug-in block, Rated current: 12 A, Rated voltage (III/2): 320 V, Number of poles: 12, Spacing: 5.08 mm, Type of connection: screw connection with tension sleeve, Color: green, Contact surface: tin.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | pin header | |
| contact surface | tin-plated | |
| Pin number | 12 pole | |
| Type of locking | No | |
| Rated voltage | 320 V | |
| Contact type | pin | |
| Grid | 5.08 mm | |
| Number of rows | 1 | |
| Additional parts | equipped | |
| Connection | screw connection | |
| Rated current | 12 A | |
| Colour | green |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
