1784897 | Phoenix Contact
Pin header, 6 pole, pitch 15 mm, straight, green, 1784897
Unit Price (€ / pc.)
42.3997 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
42.40 € *
Price list
Quantity
Price per unit*
1 pcs.
42.3997 €
10 pcs.
40.2815 €
25 pcs.
37.8658 €
50 pcs.
35.5929 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Type of locking | Yes | |
| Version | pin header | |
| Connection | screw connection | |
| Number of rows | 1 | |
| Contact type | pin | |
| Additional parts | equipped | |
| Rated voltage | 1 kV | |
| contact surface | silver-plated | |
| Pin number | 6 pole | |
| Grid | 15 mm | |
| Colour | green | |
| Rated current | 125 A | |
| Orientation | straight |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PL |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
