1768817 | Phoenix Contact

Socket header, 7 pole, pitch 5 mm, angled, green, 1768817

Order No.: 63P9042
EAN: 4017918034177
MPN:
1768817
SMSTB 2,5/ 7-ST
Series: SMSTB
1768817 Phoenix Contact PCB Connection Systems
Image may differ
Unit Price (€ / pc.)
5.9738 € *
Available in 10 days: 66 pcs. - if ordered today
Total Price:
5.97 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
5.9738 €

PCB Connector, 1768817, PHOENIX

PCB plug, rated current: 12 A, rated voltage (III/2): 320 V, number of poles: 7, grid dimension: 5 mm, connection type: screw connection with tension sleeve, color: green, contact surface: tin.

Technical specifications
Filter Property Value
Contact type socket
Orientation angled
Rated voltage 320 V
Additional parts equipped
Version socket header
Rated current 12 A
Grid 5 mm
Type of locking No
Colour green
Connection screw connection
contact surface tin-plated
Number of rows 1
Pin number 7 pole
Connection plating tin-plated
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
