1727799 | Phoenix Contact
Pin header, 12 pole, pitch 7.62 mm, angled, green, 1727799
Unit Price (€ / pc.)
21.5152 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
21.52 € *
Price list
Quantity
Price per unit*
1 pcs.
21.5152 €
10 pcs.
19.7897 €
50 pcs.
18.2070 €
100 pcs.
16.5648 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 7.62 mm | |
| contact surface | tin-plated | |
| Connection | solder connection | |
| Orientation | angled | |
| Contact type | pin | |
| Version | pin header | |
| Rated current | 41 A | |
| Colour | green | |
| Rated voltage | 630 V | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Type of locking | Yes | |
| Connection plating | tin-plated | |
| Pin number | 12 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
