1340478 | Phoenix Contact
Pin header, 6 pole, pitch 3.81 mm, angled, black, 1340478
Unit Price (€ / pc.)
1.1781 € *
Standard delivery time from the manufacturer is: 7 Weeks
PCB header, 1340478, Phoenix Contact
PCB headers, color: black, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, contact connection type: Pin, number of rows: 2, number of positions: 6, product range: DD31H 2,2/..-H, pitch: 3.81 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.8 mm, number of solder pins per potential: 1, plug-in system: CONNEXIS DD, Pin connector pattern alignment: Standard, locking: Snap-in locking, mounting: Engagement nose.
Features
- Well-known mounting principle allows worldwide use
- Plug-in direction parallel to the PCB
- Easy PCB replacement thanks to plug-in modules
- Contacts arranged in a double row enable high packing density in a compact area
- Intuitive locking mechanism prevents accidental disconnection
Technical specifications
| Version | pin header | |
| Colour | black | |
| Number of rows | 2 | |
| Rated current | 8 A | |
| Connection plating | tin-plated | |
| Type of locking | Yes | |
| Contact type | pin | |
| Connection | solder pin | |
| Orientation | angled | |
| Pin number | 6 pole | |
| Rated voltage | 160 V | |
| Additional parts | equipped | |
| Grid | 3.81 mm | |
| contact surface | tin-plated |
Download
Logistics
| Customs tariff number | 85366990 |
| Country of origin | CN |
Compliance
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
