1224227 | Phoenix Contact
Pin header, 5 pole, pitch 3.81 mm, straight, orange, 1224227
Unit Price (€ / pc.)
5.7715 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
5.77 € *
Price list
Quantity
Price per unit*
1 pcs.
5.7715 €
10 pcs.
5.3669 €
50 pcs.
4.9385 €
100 pcs.
4.4982 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB connector, 1224227, Phoenix Contact
PCB connector, nominal cross section: 1.5 mm2, color: orange, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Sn, contact connection type: Pin, number of rows: 1, number of positions: 5, product range: IMC 1,5/..-ST, pitch: 3.81 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 °, plug-in system: COMBICON MC 1,5, locking: without, mounting method: without.
Features
- Well-known connection principle allows worldwide use
- Low temperature rise, thanks to maximum contact force
- Inverted connector with pin contacts for touch-proof device outputs or free-hanging cable/cable connections
- Allows connection of two conductors
Technical specifications
| Colour | orange | |
| Type of locking | No | |
| contact surface | tin-plated | |
| Rated current | 8 A | |
| Grid | 3.81 mm | |
| Connection plating | tin-plated | |
| Pin number | 5 pole | |
| Version | pin header | |
| Orientation | straight | |
| Connection | screw connection | |
| Contact type | pin | |
| Rated voltage | 160 V | |
| Number of rows | 1 |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85366990 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
