1156917 | Phoenix Contact
Male connector, 30 pole, pitch 2.54 mm, straight, black, 1156917
Unit Price (€ / pc.)
2.0587 € *
Available in 10 days: 1,950 pcs. - if ordered today
Pin strip, 1156917, Phoenix Contact
This SMD pin header has a nominal current rating of 3 A and a test voltage of 500 V AC. It features 30 positions with a pitch of 2.54 mm, comes in black color, and has gold contact surfaces. The contact connection type is a pin, and it is designed for SMD soldering mounting.
Features
- Reliable mechanical and electrical connections thanks to the double-sided contact system
- Designed for integration into the SMT soldering process
- Clear and cost-optimized design
- Suitable for a multitude of applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact type | pin | |
| Pin number | 30 pole | |
| Grid | 2.54 mm | |
| Colour | black | |
| Version | male connector | |
| Connection | solder connection | |
| Connection plating | tin-plated | |
| Rated current | 3 A | |
| Orientation | straight | |
| Number of rows | 2 | |
| contact surface | gold-plated | |
| Type of locking | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
