1156907 | Phoenix Contact

Socket header, 80 pole, pitch 2.54 mm, angled, black, 1156907

Order No.: 64P1786
EAN: 4063151160555
MPN:
1156907
FQ 2,54D/ 80-SH-0-BT
Series: FINEPITCH
1156907 Phoenix Contact PCB Connection Systems
Image may differ
Unit Price (€ / pc.)
6.5212 € *
Available in 10 days: 440 pcs. - if ordered today
Total Price:
6.52 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
6.5212 €

Female strip, 1156907, Phoenix Contact

This SMD socket has a nominal current rating of 3 A and a test voltage of 500 V AC. It features 80 positions with a pitch of 2.54 mm, comes in black color, and has gold contact surfaces. The contact connection type is a socket, and it is designed for SMD soldering mounting.

Features

  • Reliable mechanical and electrical connections thanks to the double-sided contact system
  • Designed for integration into the SMT soldering process
  • Clear and cost-optimized design
  • Suitable for a multitude of applications
Technical specifications
Grid 2.54 mm
Version socket header
contact surface gold-plated
Connection plating tin-plated
Rated current 3 A
Contact type socket
Colour black
Number of rows 2
Pin number 80 pole
Type of locking Yes
Orientation angled
Connection solder connection
Logistics
Country of origin CN
Customs tariff number 85366930
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
