1156888 | Phoenix Contact

Socket header, 20 pole, pitch 2.54 mm, straight, black, 1156888

Order No.: 64P1713
EAN: 4063151159184
MPN:
1156888
FQ 2,54D/ 20-SV-1020-1-BT
Series: FINEPITCH
1156888 Phoenix Contact PCB Connection Systems
Image may differ
Unit Price (€ / pc.)
1.3090 € *
Available in 10 days: 2,280 pcs. - if ordered today
Total Price:
1.31 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
1.3090 €

Female strip, 1156888, Phoenix Contact

This SMD socket has a nominal current rating of 3 A and a test voltage of 500 V AC. It features 20 positions with a pitch of 2.54 mm, comes in black color, and has gold contact surfaces. The contact connection type is a socket, and it is designed for SMD soldering mounting.

Features

  • Reliable mechanical and electrical connections thanks to the double-sided contact system
  • Designed for integration into the SMT soldering process
  • Clear and cost-optimized design
  • Suitable for a multitude of applications
Technical specifications
contact surface gold-plated
Connection solder connection
Number of rows 2
Colour black
Contact type socket
Rated current 3 A
Pin number 20 pole
Orientation straight
Version socket header
Type of locking Yes
Connection plating tin-plated
Grid 2.54 mm
Logistics
Customs tariff number 85366930
Country of origin CN
Compliance
Date of RoHS guidelines 3/31/15
SVHC free No
RoHS conform Yes
