1054547 | Phoenix Contact
Pin header, 3 pole, pitch 7.62 mm, angled, green, 1054547
Unit Price (€ / pc.)
3.1654 € *
Standard delivery time from the manufacturer is: 6 Weeks
PCB header, 1054547, Phoenix Contact
PCB header, nominal cross section: 6 mm², color: green, nominal current: 41 A, rated voltage (III/2): 630 V, contact surface: Tin, contact connection type: Pin, number of potentials: 3, number of rows: 1, number of positions: 3, number of connections: 3, product range: PC 6/..-G, pitch: 7.62 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 2.6 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 6, Pin connector pattern alignment: Standard, locking: without, mounting: without.
Features
- Increased touch protection in the pin connector pattern for maximum safety even when not plugged in
- Easy PCB replacement thanks to plug-in modules
- Well-known mounting principle allows worldwide use
Technical specifications
| contact surface | tin-plated | |
| Connection | solder connection | |
| Number of rows | 1 | |
| Colour | green | |
| Contact type | pin | |
| Rated current | 41 A | |
| Rated voltage | 630 V | |
| Pin number | 3 pole | |
| Orientation | angled | |
| Version | pin header | |
| Type of locking | No | |
| Grid | 7.62 mm |
Download
Logistics
| Customs tariff number | 85366930 |
| Country of origin | CN |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
