1619848 | Phoenix Contact

Plug, 6 pole, crimp connection, screw locking, straight, 1619848

Order No.: 61P9836
EAN: 4046356821186
MPN:
1619848
CA-06P1N8AHZ00
Series: CA
1619848 Phoenix Contact Other Circular Connectors
Image may differ
Unit Price (€ / pc.)
18.7901 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
18.79 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
18.7901 €

Device connector, front mounting, 1619848, Phoenix Contact

Panel connector, rear panel, straight, shielded: yes, for standard and SPEEDCON interlocking, M23, pole count: 6, contact type: male, crimp connection, axial seal, central fixing

Technical specifications
Filter Property Value
Version plug
Orientation straight
Shell Material copper alloy
Pin number 6 pole
Cable cross-section 2.5 mm²
Contact connection crimp connection
Assembly central Mounting
Type of locking screw locking
Logistics
Property Value
Customs tariff number 85366990
Country of origin DE
Compliance
Property Value
Substance description Lead
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free No
