1619842 | Phoenix Contact

Plug, 9 pole, solder connection, screw locking, straight, 1619842

Order No.: 62P0023
EAN: 4046356821247
MPN:
1619842
CA-09P1N12HZ00
Series: CA
1619842 Phoenix Contact Other Circular Connectors
Image may differ
Unit Price (€ / pc.)
26.3704 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
26.37 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
26.3704 €

Device connector, front mounting, 1619842, Phoenix Contact

Panel connector, rear panel, straight, shielded: yes, for standard and SPEEDCON interlocking, M23, pole count: 8+1, contact type: male, solder termination, axial seal, central fixing

Technical specifications
Type of locking screw locking
contact surface nickel-plated/gold-plated
Assembly central Mounting
Contact connection solder connection
Cable cross-section 2.5 mm²
Pin number 9 pole
Version plug
Shell Material copper alloy
Orientation straight
Logistics
Country of origin DE
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
