2904620 | Phoenix Contact
Power supply, 24 to 29.5 VDC, 5 A, 120 W, 2904620
Unit Price (€ / pc.)
197.1235 € *
Available in 5 Days: 4,120 pcs. - if ordered today
Primary switched mode power supply QUINT POWER for DIN rail mounting with SFB (Selective Fuse Breaking) Technology, input: 1-phase, output: 48 V DC / 10 A
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Output voltage DC | 24 to 29.5 VDC | |
| Power | 120 W | |
| Depth | 125 mm | |
| efficiency | 89 % | |
| Height | 130.16 mm | |
| Input voltage AC | 400-500 VAC, 260-300 VDC | |
| Width | 36 mm | |
| Number of outputs | 1 | |
| Output current | 5 A | |
| Degree of protection (IP) | IP20 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TH |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
