2862204 | Phoenix Contact

Input terminal for inline station, Inputs: 8, (W x H x D) 48.8 x 119.8 x 71.5 mm, 2862204

Order No.: 64P8930
EAN: 4017918894689
MPN:
2862204
IB IL 24 DI 8/T2-PAC
Series: IB IL
2862204 Phoenix Contact Digital modules
Image may differ
Unit Price (€ / pc.)
200.5864 € *
Available in 10 days: 103 pcs. - if ordered today
Total Price:
200.59 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
200.5864 €

Digital module, 2862204, Phoenix Contact

Inline, Digital input terminal, Digital inputs: 8, 24 VDC, Connection technology: 4-conductor, Transmission speed in the local bus: 500 kbps, Degree of protection: IP20, including Inline connector and marking fields.

Features

  • Connection of sensors in 2-, 3-, and 4-conductor technology
  • Maximum permissible load current per sensor: 250 mA
  • Diagnostic and status indicators
Technical specifications
Filter Property Value
Number of digital inputs 8
Depth 71.5 mm
Version input terminal
Height 119.8 mm
Suitable for inline station
Width 48.8 mm
Assembly DIN rail
Logistics
Property Value
Country of origin DE
Customs tariff number 85389091
Compliance
Property Value
RoHS conform Yes
Substance description Lead
Date of RoHS guidelines 3/31/15
SVHC free No
