2861247 | Phoenix Contact

Input terminal for inline station, Inputs: 8, (W x H x D) 48.8 x 119.8 x 71.5 mm, 2861247

Order No.: 64P8932
EAN: 4017918894184
MPN:
2861247
IB IL 24 DI 8-PAC
Series: IB IL
2861247 Phoenix Contact Digital modules
Image may differ
Unit Price (€ / pc.)
179.69 € *
Available in 5 Days: 108 pcs. - if ordered today
Total Price:
179.69 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
179.69 €

Digital module, 2861247, Phoenix Contact

Inline, Digital input terminal, Digital inputs: 8, 24 VDC, Connection technology: 4-conductor, Transmission speed in the local bus: 500 kbps, Degree of protection: IP20, including Inline connector and marking fields.

Features

  • Connection of sensors in 2-, 3-, and 4-conductor technology
  • Maximum permissible load current per sensor: 250 mA
  • Maximum permissible load current from the terminal: 2 A
Technical specifications
Filter Property Value
Depth 71.5 mm
Number of digital inputs 8
Assembly DIN rail
Suitable for inline station
Version input terminal
Width 48.8 mm
Height 119.8 mm
Logistics
Property Value
Country of origin DE
Customs tariff number 85389091
Compliance
Property Value
Substance description Lead
SVHC free No
Date of RoHS guidelines 3/31/15
RoHS conform Yes
