1704927 | Phoenix Contact
Pin contact, 2.5-4.0 mm², AWG 14-12, crimp connection, silver-plated, 1704927
Unit Price (€ / pc.)
1.6422 € *
Standard delivery time from the manufacturer is: On Request
Pin contact, 1704927, Phoenix Contact
Panel feed-through, Range of articles: Sunclix, Device connector, Front mounting, min. Conductor cross section: 2.5 mm², max. Conductor cross section: 4 mm², Rated current: : 27 A, Connection method: Crimp, Type of contact: Pin
Features
- High-quality materials ensure a high degree of reliability and long-term stability
- Maximum system efficiency with proven, low-loss SUNCLIX contacts
- International approvals enable worldwide use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 14-12 | |
| Contact connection | crimp connection | |
| contact surface | silver-plated | |
| Version | pin contact | |
| Contact material | copper | |
| Cable cross-section | 2.5-4.0 mm² | |
| Insulation diameter | 1.9 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85359000 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
