EEUFC1V151 | Panasonic
Electrolytic capacitor, 150 µF, 35 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm, EEUFC1V151
Unit Price (€ / pc.)
0.6426 € *
Available: 80 pcs.
Total Price:
6.43 € *
Price list
Quantity
Price per unit*
10 pcs.
0.6426 €
50 pcs.
0.4760 €
250 pcs.
0.3689 €
1000 pcs.
0.3213 €
2000 pcs.
0.2844 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor, EEUFC1V151, PANASONIC
Aluminum electrolytic capacitor
Features
- Low impedance
- High rated capacitance
- RoHS-compatible
- Long useful life
Applications
- Automotive electronics
- Audio signal circuits
- Optical equipment
- Measuring equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 8 mm | |
| Ripple current | 555 mA | |
| max. operating temperature | 105 °C | |
| Rated voltage (DC) | 35 V | |
| Length | 11.5 mm | |
| Grid | 3.5 mm | |
| Capacity | 150 µF | |
| Design | radial | |
| min. operating temperature | -55 °C | |
| Tolerance | ±20 % | |
| ESR (Equivalent Series Resistance) | 117 mΩ | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Original Packaging | Bulk with 200 pieces |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
