1461492-2 | OEG
Relay, 1 Form A (N/O), 5 V (DC), 100 Ω, 5 A, 250 V (AC), monostable, 1461492-2
Order No.: 30G8605
MPN:
1461492-2
Unit Price (€ / pc.)
2.5585 € *
Available in 5 Days: 6,229 pcs. - if ordered today
Total Price:
2.56 € *
Price list
Quantity
Price per unit*
1 pcs.
2.5585 €
10 pcs.
2.3800 €
25 pcs.
2.2253 €
50 pcs.
2.0230 €
*incl. VAT plus shipping costs
Subject to prior sale
General Purpose Power Relay, 1461492-2, OEG
General Purpose Power Relay, DC, Monostable, 1 Form A SPST-NO, 5 A Contact Rating, 5 VDC Coil Voltage, OEG Miniature PCB Relay OJT.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Coil voltage (DC) | 5 V | |
| Connection | solder pin | |
| Contact material | AgSnO | |
| switching current | 5 A | |
| Coil resistance | 100 Ω | |
| Switching Voltage (AC) | 250 V | |
| Coil type | monostable | |
| Contact type | 1 Form A (N/O) |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85364190 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
