00 6124 24 | Neosid

Suppressor choke, radial, 10 mH, 15 mA, 00 6124 24

Order No.: 75D6248
EAN: 4099889040913
MPN:
00 6124 24
Series: Bs75
Neosid
default L
front L
Image may differ
Unit Price (€ / pc.)
1.9397 € *
Available: 908 pcs.
Leadtime: 25 Weeks **
Total Price:
19.40 € *
Price list
Quantity
Price per unit*
10 pcs.
1.9397 €
50 pcs.
1.7017 €
250 pcs.
1.4637 €
1000 pcs.
1.2852 €
2500 pcs.
1.1662 €
*incl. VAT plus shipping costs
**Subject to prior sale

Suppressor inductor, 00 6124 24, NEOSID

The 00 6124 24 is a fixed value choke inductor with or without a ferromagnetic core, used to block alternating current (AC) in a circuit by limiting the rate of change over a specified frequency range, while allowing passage of lower frequency AC or direct current (DC).

Features

  • Solderability as per DIN IEC 68-2-20 Ta

Applications

  • Decoupling of high and low frequency circuits
  • Telecommunications
  • Video equipment
  • Electronic data processing systems
Technical specifications
Version suppressor choke
Design radial
Width 6 mm
DC current 15 mA
DC resistance 50 Ω
Quality Q Q 65
Height 8.5 mm
Inductance 10 mH
Length 11.4 mm
Measuring frequency 100 kHz
Saturation current 15 mA
Tolerance ±5 %
Logistics
Country of origin DE
Customs tariff number 85045000
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
Tolerance
Inductance
DC current
DC resistance
Design
Version
Width
Length
Height
1 item in 6 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
Tolerance
Inductance
DC current
DC resistance
Design
Version
Width
Length
Height
Suppressor choke, radial, 4.7 mH, 22 mA, 00 6124 20
Order No.:
 75D6240
Manufacturer:
 Neosid
Manufacturer SKU:
 00 6124 20
Available: 134 pcs. Leadtime: 25 Weeks **
Total Price: 19.40 € *
10 pcs.
1.9397 €
50 pcs.
1.7017 €
250 pcs.
1.4637 €
1000 pcs.
1.2852 €
2500 pcs.
1.1662 €
±5 %
4.7 mH
22 mA
20 Ω
radial
suppressor choke
6 mm
11.4 mm
8.5 mm
Suppressor choke, radial, 47 mH, 700 mA, 00 6124 32
Order No.:
 75D6264
Manufacturer:
 Neosid
Manufacturer SKU:
 00 6124 32
Available: 1,453 pcs. Leadtime: 25 Weeks **
Total Price: 12.38 € *
10 pcs.
1.2376 €
50 pcs.
1.0948 €
250 pcs.
0.9401 €
1000 pcs.
0.8211 €
2500 pcs.
0.7497 €
±10 %
47 mH
700 mA
250 Ω
radial
suppressor choke
6 mm
11.4 mm
8.5 mm
Suppressor choke, radial, 10 mH, 15 mA, 00 6124 24
Order No.:
 75D6248
Manufacturer:
 Neosid
Manufacturer SKU:
 00 6124 24
Available: 908 pcs. Leadtime: 25 Weeks **
Total Price: 19.40 € *
10 pcs.
1.9397 €
50 pcs.
1.7017 €
250 pcs.
1.4637 €
1000 pcs.
1.2852 €
2500 pcs.
1.1662 €
±5 %
10 mH
15 mA
50 Ω
radial
suppressor choke
6 mm
11.4 mm
8.5 mm
Suppressor choke, radial, 1 mH, 50 mA, 00 6124 12
Order No.:
 75D6224
Manufacturer:
 Neosid
Manufacturer SKU:
 00 6124 12
Available: 0 pcs. Leadtime: 14 Weeks **
Total Price: 1.94 € *
10 pcs.
1.9397 €
50 pcs.
1.7017 €
250 pcs.
1.4637 €
1000 pcs.
1.2852 €
2500 pcs.
1.1662 €
±5 %
1 mH
50 mA
8.6 Ω
radial
suppressor choke
6 mm
11.4 mm
8.5 mm
Suppressor choke, radial, 1.5 mH, 420 mA, 00 6124 14
Order No.:
 75D6228
Manufacturer:
 Neosid
Manufacturer SKU:
 00 6124 14
Available: 0 pcs. Leadtime: 25 Weeks **
Total Price: 1.65 € *
1 pcs.
1.6541 €
10 pcs.
1.1781 €
50 pcs.
1.0115 €
100 pcs.
0.8806 €
500 pcs.
0.7973 €
±10 %
1.5 mH
420 mA
11 Ω
radial
suppressor choke
6 mm
11.4 mm
8.5 mm
Suppressor choke, radial, 100 µH, 150 mA, 00 6124 00
Order No.:
 75D6200
Manufacturer:
 Neosid
Manufacturer SKU:
 00 6124 00
Available: 0 pcs. Leadtime: 25 Weeks **
Total Price: 1.01 € *
2000 pcs.
1.0115 €
±5 %
100 µH
150 mA
1.2 Ω
radial
suppressor choke
6 mm
11.4 mm
8.5 mm
