TDR-960-48. | MEAN WELL
Power supply, 48 to 55 VDC, 20 A, 960 W, TDR-960-48.
This item is no longer available.
As an alternative, we recommend the following item:
Power supply, 48 to 55 VDC, 20 A, 960 W, TDR-960-48
Order No.: 62C2133
Manufacturer: MEAN WELL
per pc. 272.5100 € *
Power supply, TDR-960-48, MEAN WELL
AC-DC Industrial 3-phase DIN rail power supply, output 48 VDC at 20 A, metal housing, 2-phase operation possible, current division 3+1.
Features
- Three-phase 340-550 VAC Wide range input
- Width only 110 mm
- High efficiency 94.5 % and low power dissipation
- Protection functions: Short circuit, overload, overvoltage, overtemperature
- Cooling by free air convection
- Built-in DC OK relay contact
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 20 A | |
| Output voltage DC | 48 to 55 VDC | |
| Input voltage AC | 340-550 VAC, 480-780 VDC | |
| Power | 960 W | |
| efficiency | 94.55 % | |
| Width | 110 mm | |
| Height | 125.2 mm | |
| Depth | 150 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85043180 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
