NDR-240-24 | MEAN WELL
Power supply, 24 VDC, 10 A, 240 W, NDR-240-24
Active
Product by MEAN WELL at Bürklin Elektronik
Power supply unit, NDR-240-24, MEANWELL
The NDR series of cost-effective, slim-line power supplies (PSUs) can be installed on TS-35/7.5 or TS-35/15 mounting rails and are designed to save space in cabinets. The entire series complies with EN61000-3-2 and is designed with a metal housing that increases the power dissipation of the power supplies.
Features
- Universal AC input/full range
- Short circuit/overload/overvoltage/overtemperature protection
- Cooling by free air convection
- UL 508 (industrial control equipment) approved
| Number of outputs | 1 | |
| Output voltage DC | 24 VDC | |
| Output current | 10 A | |
| Width | 63 mm | |
| Input voltage AC | 90-264 VAC, 127-370 VDC | |
| Height | 125 mm | |
| Length | 113 mm | |
| Power | 240 W | |
| Degree of protection (IP) | IP20 | |
| Depth | 113 mm | |
| efficiency | 88.5 % |
| Country of origin | CN |
| Customs tariff number | 85043180 |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
