HDR-150-12 | MEAN WELL

AC/DC Industrial Power Supply, HDR-150-12, MEAN WELL

The HDR-150-12 is an economical ultra slim 150W DIN rail power supply, designed to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body has a width of 105mm (6SU), allowing space-saving installation inside cabinets. HDR-150-12 accepts full-range AC input from 85VAC to 264VAC (277VAC operational) and conforms to BS EN/EN61000-3-2, the European Union standard for harmonic current. The plastic housing provides effective protection against electrical hazards. With a working efficiency of up to 90.5%, HDR-150-12 can operate at ambient temperatures between -30°C and 70°C under air convection. Complete protection functions and relevant certifications for home automation and industrial control apparatus (IEC62368-1, UL62368-1, UL61010, BS EN/EN61558-2-16) make HDR-150-12 a highly competitive power supply solution for household and industrial applications.

Features

• No load power consumption<0.3W
• Isolation class II
• DC output voltage adjustable
• Cooling by free air convection
• LED indicator for power on

Applications

• Household control system
• Building automation
• Industrial control system
• Factory automation
• Electro-mechanical apparatus
