RSP-500-12 | MEAN WELL
Switching power supply, 10-13.2 VDC, 41.7 A, 500.4 W, RSP-500-12
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
72.8399 € *
Available in 5 Days: 58 pcs. - if ordered today
AC/DC Industrial Power Supply, RSP-500-12, MEAN WELL
The RSP-500-12 is a 500W single-output enclosed type AC/DC power supply. It operates with an input voltage of 85 - 264VAC and offers DC output models most commonly demanded by the industry. Each model is cooled by a built-in fan with fan speed control, supporting operation up to 70°C. RSP-500-12 provides design flexibility with built-in functions such as remote ON-OFF control, remote sense, and DC OK signal.
Features
- Universal AC input/ Full range
- Built-in active PFC function
- High efficiency up to 90.5%
- Forced air cooling by built-in DC fan
Applications
- Test and measurement instrument
- Laser related machine
- Burn-in facility
- RF application
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 41.7 A | |
| Output voltage DC | 10-13.2 VDC | |
| Input voltage AC | 85-264 VAC/120-370 VDC | |
| Power | 500.4 W | |
| efficiency | 88 % | |
| Length | 230 mm | |
| Width | 127 mm | |
| Height | 40.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85044083 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
