KRE 04 | Lumberg

PCB terminal, 4 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 04

Lumberg
default L
default S
Images may differ
Order No.:  09H5862
Manufacturer:  Lumberg
Manufacturer SKU: KRE 04
Manufacturer series:  KRE
EAN: 4099891038793
about the green icons
Total price
( 1.4280 € * / pcs.)
14.28 €
Available: 142 pcs.
Next delivery: 1,000 pcs. on 2023-12-08
Leadtime
Quantity
Price per unit*
10 pcs.
1.4280 €
50 pcs.
1.2495 €
250 pcs.
1.0829 €
1000 pcs.
0.9520 €
2500 pcs.
0.8568 €
*incl. VAT plus shipping costs
Show 10 variants
Description
Technical specifications
Logistics
Compliance
Download
Variations
Description

Screw terminal block,

For vertical mounting on PCBs, with single-row solder terminals and misplacement protection. Practical splitting for user-specific in-line installation; Contact carrier: PA 6.6, V2 to UL 94, light-gray. Terminal body: steel, galvanized and chromalized. Grid: 5.0 mm. Screw: M 2.6. Conductor cross-sections: max. 4.0 mm². Rated current: 15 A. Rated voltage to DIN VDE 0110/IEC 60664: 250 VAC. Test Voltage: 3.0 kV/60 s. Leakage current resistance: CTI 600. Air gap/creepage distance: to DIN VDE 0110/IEC 60664: 3.6/3.6 mm. Operating temperatures: –25 to +100 °C. Certifications: UL, CSA.

Technical attributes (type, number of poles, strip length): KRE 04, 4–pole, 20 mm
Technical specifications
Connection screw connection
AWG cross-section AWG 22-14
Width 10 mm
Colour light gray
Height 19.3 mm
Contact distance RM 5/5.08
Cable cross-section 4.0 mm²
Rated voltage 250 V
Rated current 15 A
Pin number 4 pole
Grid 5 mm
Depth 15.5 mm
Show similar products (0)
Logistics
Country of origin DE
Customs tariff number 85366990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
Pin number
Cable cross-section
Depth
Unit
Width
Unit
Grid
Unit
Height
Unit
Connection
Colour
Rated voltage
Unit
AWG cross-section
Contact distance
Rated current
Unit
Search results: 1 item in 10 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
Availability
Pin number
Cable cross-section
Depth
Width
Grid
Height
Connection
Colour
Rated voltage
AWG cross-section
Contact distance
Rated current
PCB terminal, 2 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 02
PCB terminal, 2 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 02
Order No.:
 09H585
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 02
11.54 € *
10 pcs.
1.1543 €
50 pcs.
1.0115 €
250 pcs.
0.8687 €
1000 pcs.
0.7616 €
Available: 639 pcs.
Next delivery: 900 pcs. on 2023-10-27
Leadtime
2 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 4 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 04
PCB terminal, 4 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 04
Order No.:
 09H5862
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 04
14.28 € *
10 pcs.
1.4280 €
50 pcs.
1.2495 €
250 pcs.
1.0829 €
1000 pcs.
0.9520 €
2500 pcs.
0.8568 €
Available: 142 pcs.
Next delivery: 1,000 pcs. on 2023-12-08
Leadtime
4 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 6 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 06
PCB terminal, 6 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 06
Order No.:
 09H587
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 06
2.19 € *
1 pcs.
2.1896 €
25 pcs.
1.8564 €
100 pcs.
1.7136 €
250 pcs.
1.6184 €
1000 pcs.
1.4875 €
Available: 319 pcs.
Leadtime
6 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 18 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 18
PCB terminal, 18 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 18
Order No.:
 09H5868
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 18
3.74 € *
1 pcs.
3.7366 €
Available: 928 pcs.
Leadtime
18 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 8 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 08
PCB terminal, 8 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 08
Order No.:
 09H5864
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 08
2.75 € *
1 pcs.
2.7489 €
25 pcs.
2.3324 €
100 pcs.
2.1658 €
250 pcs.
2.0587 €
1000 pcs.
1.8802 €
Available: 702 pcs.
Leadtime
8 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 12 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 12
PCB terminal, 12 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 12
Order No.:
 09H588
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 12
3.96 € *
1 pcs.
3.9627 €
10 pcs.
3.4867 €
100 pcs.
3.0583 €
250 pcs.
2.9393 €
1000 pcs.
2.7489 €
Available: 367 pcs.
Leadtime
12 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 7 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 07
PCB terminal, 7 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 07
Order No.:
 09H5872
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 07
1.33 € *
1 pcs.
1.3328 €
Available: 2,144 pcs.
Leadtime
7 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 9 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 09
PCB terminal, 9 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 09
Order No.:
 09H5865
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 09
3.06 € *
1 pcs.
3.0583 €
10 pcs.
2.6894 €
100 pcs.
2.3562 €
250 pcs.
2.2729 €
1000 pcs.
2.1182 €
Available: 38 pcs.
Leadtime
9 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 3 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 03
PCB terminal, 3 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 03
Order No.:
 09H586
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 03
12.14 € *
10 pcs.
1.2138 €
50 pcs.
1.0591 €
250 pcs.
0.9282 €
1000 pcs.
0.8092 €
2500 pcs.
0.7378 €
Available: 974 pcs.
Leadtime
3 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
PCB terminal, 5 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 05
PCB terminal, 5 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 05
Order No.:
 09H5863
Manufacturer:
 Lumberg
Manufacturer SKU:
 KRE 05
1.18 € *
200 pcs.
1.1781 €
600 pcs.
1.1186 €
1000 pcs.
1.0115 €
Available: 0 pcs.
Next delivery: 800 pcs. on 2023-10-27
Leadtime
5 pole
4.0 mm²
15.5 mm
10 mm
5 mm
19.3 mm
screw connection
light gray
250 V
AWG 22-14
RM 5/5.08
15 A
