3114 04 VP15 | Lumberg

Name: Socket housing, 4 pole, pitch 2.5 mm, straight, black, 3114 04 VP15
Brand: Lumberg
SKU: 41P1477
Price: 0.22 EUR
Availability: InStock

Socket housing, 4 pole, pitch 2.5 mm, straight, black, 3114 04 VP15

Order No.: 41P1477

EAN: 4099889980486

MPN:

3114 04 VP15

Series: 3114

Image may differ

Key Specification:

Version socket housing

Contact type socket

Pin number 4 pole

Grid 2.5 mm

Connection crimp connection

Ordering Information:

Supplied without contacts, please order these separately

Show 18 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.2166 € *

Available: 18,465 pcs.

Leadtime: 13 Weeks **

Total Price:

2.17 € *

Price list

Quantity

Price per unit*

10 pcs.

0.2166 €

100 pcs.

0.1952 €

500 pcs.

0.1856 €

2500 pcs.

0.1725 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Minimodul connector, 3853 04 30 04, Lumberg

Multimodul pin header, angular, with locking latch, with retaining hooks

Download

Technical Data Sheet - EN Technical Data Sheet

Product Change Notification - EN/DE Product Change Notification

Declaration of Conformity - EN Declaration of Conformity

Technical Data Sheet - DE Technical Data Sheet

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	DE
Customs tariff number	39269097
Original Packaging	Carton with 2,500 pieces

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

Accessory

Pin header, 4 pole, pitch 2.5 mm, angled, black, 2,5 MSFW 04

Order No.:

56F5678

Manufacturer SKU:

2,5 MSFW 04

Available: 3,087 pcs. Leadtime: 7 Weeks **

0.45 € per pc. *

*incl. VAT plus shipping costs

**Subject to prior sale

Receptacle, 0.1-0.25 mm², crimp connection, tin-plated, 3111 01 G500
