S4X8TS2RP | Littelfuse
Thyristor, S4X8TS2RPAH
Order No.: 74P0597
EAN: 4099891774622
MPN:
S4X8TS2RP
Unit Price (€ / pc.)
0.3213 € *
Available: 0 pcs.
Leadtime: 15 Weeks **
Thyristor, S4X8TS2RP, Littelfuse
The S4X8TS2RP offer high static dv/dt and lower turn-off (Tq) sensitive SCR with its small die planar construction design. It is specifically designed for GFCI (Ground Fault Circuit Interrupter) and gas ignition applications. All SCRs junctions are glass-passivated to ensure long term reliability and parametric stability.
Features
- RoHS compliant
- Halogen-free
- High dv/dt noise immunity
- Sensitive gate for direct microprocessor interface
Applications
- The device is specifically designed for GFCI (Ground Fault Circuit Interrupter) and gas ignition applications
Technical specifications
| Number of pins | 4 | |
| Gate trigger voltage | 0.8 V | |
| Gate trigger current | 0.05 mA | |
| Enclosure | SOT-223 | |
| max. holding current | 5 mA | |
| max. operating temperature | 125 °C | |
| min. operating temperature | -40 °C | |
| Assembly | SMD | |
| Voltage V RRM (peak reverse voltage) | 400 V |
Download
Logistics
| Country of origin | PH |
| Customs tariff number | 85413000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
