37001000430 | Littelfuse

Micro fuse TR5, 100 mA, F, 250 V (AC), 35 A breaking capacity, 37001000430

Order No.: 46G5388
EAN: 4099889091694
MPN:
37001000430
Series: 370
37001000430 Littelfuse Micro Fuses
Image may differ
Unit Price (€ / pc.)
1.1662 € *
Available: 324 pcs.
Total Price:
1.17 € *
Price list
Quantity
Price per unit*
1 pcs.
1.1662 €
10 pcs.
0.8330 €
100 pcs.
0.7140 €
500 pcs.
0.6188 €
1000 pcs.
0.5593 €
*incl. VAT plus shipping costs
Subject to prior sale

Micro fuse, 37001000430,LITTELFUSE

The 37001000430 is a sub miniature fast-acting fuse with that is designed to protect less sensitive components and is also used to protect cabling from melting or catching fire when an overload occurs.

Features

  • Reduced PCB space requirements
  • Shock safe casing
  • RoHS-compliant and Halogen-free
  • Low internal resistance

Applications

  • Battery chargers
  • Power supplies
  • Consumer electronics
  • Industrial controllers
Technical specifications
Filter Property Value
Tripping characteristics F
Rated voltage (AC) 250 V
Length 8 mm
Design TR5
Breaking capacity 35 A
diameter 8.5 mm
Version micro fuse
Rated current 100 mA
Logistics
Property Value
Country of origin PH
Customs tariff number 85361010
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
