0326020.HXP | Littelfuse

Microfuse 6.3 x 32 mm, 20 A, T, 250 V (AC), 400 A breaking capacity, 0326020.HXP

Order No.: 55P6916
EAN: 4099889099294
MPN:
0326020.HXP
Series: 326
0326020.HXP Littelfuse Micro Fuses
Image may differ
Unit Price (€ / pc.)
0.8925 € *
Available in 4 Days: 200 pcs. - if ordered today
Total Price:
89.25 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 pcs.
0.8925 €

Fuse, 0326020.HXP, Littelfuse

The 3AB Slo-Blo fuse with ceramic body construction permits higher interrupting ratings and voltage ratings. Ideal for applications where high current loads are expected.

Features

  • In accordance with UL Standard 248-14
  • Available in cartridge and axial lead format and with various forming dimensions
  • RoHS compliant and Lead-free
Technical specifications
Enclosure ceramic tube
Rated current 20 A
diameter 6.9 mm
Tripping characteristics T
Length 32.72 mm
Breaking capacity 400 A
Rated voltage (AC) 250 V
Version microfuse
Design 6.3 x 32 mm
Logistics
Country of origin CN
Customs tariff number 85361010
Original Packaging Bulk with 100 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
