35266.000.000 | LEAR Corporation
Insulated flat plug sleeve, 9.5 x 1.2 mm, 4.0 to 6.0 mm², AWG 12 to 10, brass, tin-plated, yellow, 35266.000.000
Order No.: 05F542
EAN: 4099889618570
MPN:
35266.000.000
No longer in assortment
Unit Price (€ / pc.)
0.5355 € *
Available: 181 pcs.
Total Price:
5.35 € *
Price list
Quantity
Price per unit*
10 pcs.
0.5355 €
100 pcs.
0.4760 €
500 pcs.
0.4165 €
1000 pcs.
0.3570 €
5000 pcs.
0.3023 €
*incl. VAT plus shipping costs
Subject to prior sale
Receptacle, 35266.000.000, LEAR Corporation
Receptacle, insulated, made of tinned brass; Insulation: PVC.
Mating width 9.5 mm, type 35266.
Dimensions: l1 27, l2 12 mm.
Technical attributes (type, mating width x mating thickness, for conductor cross-section. color): 35266, 9.5 x 1.2 mm, 4.0 to 6.0 mm², yellow.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | flat plug sleeve | |
| Suitable for | 9.5 x 1.2 mm | |
| Material | brass, tin-plated | |
| Isolated | Yes | |
| Insulation colour | yellow | |
| Connection | crimp connection | |
| Cable cross-section | 4.0 to 6.0 mm² | |
| AWG cross-section | AWG 12 to 10 | |
| Length | 27 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | SK |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
