0023138 | LAPP
Copolymer-photovoltaic cable, halogen free, ÖLFLEX SOLAR XLS-R, 6.0 mm², black, outer Ø 5.8 mm, 0023138
Order No.: 33P2299
EAN: 4044776124900
MPN:
0023138
ÖLFLEX SOLAR XLS-R 1X6 WH/BK
Series: ÖLFLEX SOLAR XLS-R
Unit Price (€ / mtr.)
3.1178 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
3.12 € *
Price list
Quantity
Price per unit*
1 mtr.
3.1178 €
10 mtr.
2.6894 €
50 mtr.
2.4871 €
100 mtr.
2.3086 €
500 mtr.
2.1539 €
*incl. VAT plus shipping costs
Subject to prior sale
Solar cable, 0023138, LAPP
The 0023138 is a electron beam cross-linked solar cable with reduced outer diameter. This cross-linked, halogen free and double insulated solar cable is suitable for permanent outdoor use and especially for the interconnection of grounded and ungrounded photovoltaic power system. It is applicable for the connection of solar panel among themselves and as extension cable between the individual module strings or the DC/AC inverter.
Features
- Good notch and abrasion resistance
- Proven electron beam cross-linked quality
- UV-resistant
- Solar Energy
- Cold-resistant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | Yes | |
| Bending radius moved | 93 mm | |
| Colour | black | |
| Test voltage | 6.5 kV | |
| Cable cross-section | 6.0 mm² | |
| Outer diameter | 5.8 mm | |
| Rated voltage U0 | 600 V | |
| Rated voltage | 1 kV | |
| Bending radius unmoved | 31 mm | |
| Temperature range (unmoved) | -40°C to 100 °C | |
| Core insulation material | copolymer | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, tin-plated |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444999 |
| Country of origin | KR |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
